Mitsubishi R2500
| | 1970 - 1975 |
| Compact Utility tractor |
|
Series map:
R2000
R2500
19.7hp
25.0hp
| Production |
| Manufacturer | Mitsubishi
|
| Compact Utility tractor |
| Variants |
| R2500HC | high clearance
|
| Mitsubishi R2500 Power |
| Engine | 25 hp
18.6 kW
|
| Mechanical |
| Two-wheel drive |
| Final drives | spur gear
|
| Differential lock | mechanical rear
|
| Manual steering |
| Mechanical drum brakes |
| Open operator station. |
| Photos |
| No photos of the Mitsubishi R2500 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Tractor hitch |
| Rear Type | I
|
| Control | position control with optional draft control
|
| Rear lift (at ends) | 1750 lbs
793 kg
|
| Power Take-off (PTO) |
| Clutch | 544:2400
|
| | 835:2400
|
| Rear PTO Type | 540 (1.375)
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| Farm Tractor R2500 published in 1969, by Mitsubishi |
