CaseIH Farmall 35C


CaseIH Farmall 35C tractor photo
2014 - 2021
Model year
Farmall C Series
Compact Utility tractor
Farmall 35B
Series:Farmall 30CFarmall 35CFarmall 40C
Production
Manufacturer:CaseIH
Type:Compact Utility tractor
Original price:$25,860 (2016 shuttle ROPS )
Original price:$33,215 (2016 hydro cab )
CaseIH Farmall 35C Power
Engine:36.2 hp
27.0 kW
Shuttle PTO (claimed):29.6 hp
22.1 kW
Hydro PTO (claimed):28.1 hp
21.0 kW
CaseIH Farmall 35C Engine
Shibaura 1.5L 3-cyl diesel
ROPS Fuel tank:10.5 gal
39.7 L
Cab Fuel tank:12.4 gal
46.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional.
Transmissions:12-speed synchronized shuttle
 hydrostatic
Transmission details ...
Photos
No photos of the CaseIH Farmall 35C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Valves:1 or 2
Pump flow:7.3 gpm
27.6 lpm
Tractor hitch
Rear Type:I
Control:position control
Rear lift (at ends):1808 lbs
820 kg
Rear lift (at 24"/610mm):1433 lbs
650 kg
Rear Arms:telescopic link ends
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
Wheelbase:66 inches
167 cm
Weight:3218 to 3589 pounds
Front tire:7x14
Rear tire:11.2x24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:85
Battery volts:12
