Kioti DK5010


Kioti DK5010 tractor photo
2015 -
DK10 Series
Compact Utility tractor
Series map:
DK4510
DK5010
DK5510
45.0hp
50.0hp
55.0hp
Production
ManufacturerKioti (a part of Daedong)
Compact Utility tractor
Kioti DK5010 Engine
Daedong 1.8L 3-cyl diesel
Fuel tank11.9 gal
45.0 L
Engine details ...
Kioti DK5010 Transmissions
8-speed mechanical shuttle
8-speed power shuttle
Transmission details ...
Kioti DK5010 Power
Engine (gross)50 hp
37.3 kW
PTO (claimed)45.6 hp
34.0 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post folding ROPS.
Hydraulics
Typeopen center
Valves2 OptOptional
Total flow14.5 gpm
54.9 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at 24"/610mm)2716 lbs
1231 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Dimensions & Tires
Wheelbase71.3 inches
181 cm
Weight3373 lbs
1529 kg
Front tire8-16
Rear tire13.6-24
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
DK5010 references literature
DK 10 Series published in 2015, by Kitoi
DK 10 Series published in 2021, by Kitoi
