UTB/Universal U-650M
|
|
| Production | |
| Manufacturer | UTB/Universal |
| Utility tractor | |
| Built in Brasov, Romania | |
| UTB/Universal U-650M Engine | |
| UTB 4.8L 4-cyl diesel | |
 Engine details ... |
| UTB/Universal U-650M Transmission | |
| 10-speed gear | |
 Transmission details ... |
| UTB/Universal U-650M Power | |
| Engine | 65 hp 48.5 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Steering | power |
| Dry disc brakes | |
| Open operator station. Cab optional. | |
| Hydraulics | |
| Type | open center |
| Pressure | 1711 psi 118.0 bar |
| Pump flow | 10.6 gpm 40.1 lpm |
| Tractor hitch | |
| Rear Type | II |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 95.7 inches 243 cm |
| Weight | 7452 lbs 3380 kg |
| Front tire | 6.50-20 |
| Rear tire | 14-38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 36 |
| Charging volts | 12 |
| Battery volts | 12 |
| Battery AH | 53 |
| References | |
 | |
| 650M published by Universal | |
| U-650M Instruction Book |
