Massey Ferguson 4780
|
|
| Production | |
| Distributor | Massey Ferguson |
| Manufacturer | Müller |
| Four-wheel Drive (4WD) tractor | |
| Built in Brazil | |
| Massey Ferguson 4780 Engine | |
| Scania 11.0L 6-cyl diesel | |
 Engine details ... |
| Massey Ferguson 4780 Transmission | |
| 10-speed constant mesh | |
 Transmission details ... |
| Massey Ferguson 4780 Power | |
| Engine | 215 hp 160.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Articulated power steering | |
| Hydraulic disc brakes | |
| Cab standard with available heat and air-conditioning. |
| Photos | |
| No photos of the Massey Ferguson 4780 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 147.9 gal 559.8 L |
| Hydraulic system | 26.4 gal 99.9 L |
| Hydraulics | |
| Capacity | 26.4 gal 99.9 L |
| Pressure | 2077 psi 143.2 bar |
| Valves | 2 |
| Pump flow | 18.2 gpm 68.9 lpm |
| Tractor hitch | |
| Rear Type | III |
| Rear lift | 11680 lbs 5298 kg |
| Dimensions & Tires | |
| Wheelbase | 117.9 inches 299 cm |
| Weight | 20610 lbs 9348 kg |
| Front tire | 18.4/15x34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 55 |
| Battery volts | 12 |
| Battery AH | 165 |
| References | |
 | |
| MF 4780 published by Massey Ferguson |
