John Deere 5090GN
|
|
| Production | |
| Manufacturer | John Deere |
| Orchard/Vineyard tractor | |
| John Deere 5090GN Engine | |
| FPT 3.4L 4-cyl diesel | |
| Fuel tank | 19.3 gal 73.1 L |
| 26.8 gal*With optional auxiliary tank 101.4 L | |
 Engine details ... | |
| John Deere 5090GN Transmissions | |
| 24-speed | |
| 12-speed | |
 Transmission details ... |
| John Deere 5090GN Power | |
| Engine (gross) | 90 hp 67.1 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | electrohydraulic |
| Power steering | |
| Hydraulic wet disc brakes | |
| Two-post foldable mid-mount ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the John Deere 5090GN are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 0 to 4 |
| Mid valves | 0 to 4 |
| Pump flow | 17.6 gpm 66.6 lpm |
| 7.9 gpm*Optional, third pump. 29.9 lpm | |
| Total flow | 25.5 gpm 96.5 lpm |
| 33.4 gpm*With third pump 126.4 lpm | |
| Steering flow | 7.9 gpm 29.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | center link draft sensing |
| Rear lift (at ends) | 5710 lbs 2590 kg |
| 6834 lbsOptOptional 3099 kg | |
| Rear Arms | fixed ball ends |
| adjustable ball ends OptOptional | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | mechanical dry disc |
| hydraulic wet disc *With PowrReverser transmission. | |
| Rear PTO Type | 540/540E |
| Dimensions & Tires | |
| Weight | 5566 to 6558 pounds |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Specialty Series published in 2020, by John Deere | |
| Specialty Series published in 2020, by John Deere |
