Tractors > John Deere > 8200

John Deere 8200



John Deere 8200 tractor photo
1995 - 1999
Model year
8000/8000T Series
Row-Crop tractor
Series map:
8100
8200
8300
177.8hp*
200.0hp*
222.2hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Variants
8200wheeled tractor
8200Tcrawler tractor
John Deere 8200 Engine
John Deere 8.1L 6-cyl diesel
Engine details ...
John Deere 8200 Transmission
16-speed full power shift
Transmission details ...
John Deere 8200 Power
PTO (claimed)180 hp
134.2 kW
Drawbar (tested)159.63 hp
119.0 kW
PTO (tested)206.36 hp
153.9 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic
Power steering
Differential hydraulic wet disc brakes
CommandView Cab standard. Row-Trak guidance optional.
Photos
No photos of the John Deere 8200 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel135 gal
511.0 L
Hydraulic system37 gal
140.0 L
Front hubs3.2 qts (each)
3.0 L
Front diff.11.5 qts
10.9 L
Hydraulics
Typeclosed center pressure-flow compensated (PFC)
Capacity37 gal
140.0 L
Pressure2900 psi
200.0 bar
Valves3 to 5
SCV flow30 gpm
113.6 lpm
Tractor hitch
Rear Type3/3N
Controlelectro-hydraulic draft sensing
Rear lift10,400 lbs
4717 kg
 14,165 lbs (optional)
6425 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
 540/1000 (1.375 optional)
Dimensions & Tires
2WD Wheelbase122.8 inches
311 cm
4WD Wheelbase116.1 inches
294 cm
Weight16457 to 18928 pounds
Front tire11.00-24
2WD Rear tire18.4R46
Full dimensions and tires ...
8200 Serial Number Location
John Deere 8200 serial number location
Serial number plate on the rear of the tractor, above the PTO shaft.
8200 Serial Numbers
19951001
19963001
199710001
199820001
199924001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps140
Batteries2
Battery CCA1,850
Battery volts12
References
8200 references literature
8000/8000T Series Tractors Product Information Handbook published in 1998, by John Deere
