SAME Row Crop 90
|
|
| Production | |
| Manufacturer | SAME |
| High-Clearance tractor | |
| SAME Row Crop 90 Engine | |
| SAME 4.0L 4-cyl diesel | |
| Fuel tank | 24 gal 90.8 L |
 Engine details ... | |
| SAME Row Crop 90 Transmission | |
| 20-speed synchronized | |
 Transmission details ... |
| SAME Row Crop 90 Power | |
| Engine | 88 hp 65.6 kW |
| PTO (claimed) | 81 hp 60.4 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | mechanical |
| Power steering | |
| Hydraulic wet disc brakes | |
| Four-post ROPS. | |
| Photos | |
 | |
 SAME Row Crop 90 photos... | |
| Hydraulics | |
| Valves | 2 |
| Pump flow | 15.8 gpm 59.8 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position, float, and draft control |
| Rear lift | 6473 lbs 2936 kg |
| 8900 lbsOptOptional 4037 kg | |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Rear PTO Type | 540/1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 90.6 inches 230 cm |
| Weight | 7501 lbs 3402 kg |
| Front tire | 7.50-20 |
| 2WD Rear tire | 13.6R38 |
 Full dimensions and tires ... | |
| References | |
 | |
| SAME Tractors that are true specialists published by AGCO |
