Tractors > CaseIH > Farmalll 110A

CaseIH Farmalll 110A Tests



CaseIH Farmalll 110A tractor photo
2012 - 2025
Model year
Farmall 100A Series
Utility tractor
Series map:
Farmalll 110A
Farmall 120A
110.0hp
120.0hp
OCED Tractor Test 2156A
Farmalll 110A fuel use from test 1037A
OCED Tractor Test 2156A
Diesel 8-speed 4WD
August 30 - September 7, 2016
Link: OCED Tractor Test 2156A file
PTO performance
Max power94.93 hp
70.8 kW
Fuel use5.2 gal/hour
19.7 l/hour
Power at rated engine speed92.57 hp
69.0 kW
Fuel use5.9 gal/hour
22.3 l/hour
Power at rated PTO speed94.56 hp
70.5 kW
Fuel use5.4 gal/hour
20.4 l/hour
Drawbar performance
Max power80.30 hp
59.9 kW
Fuel use5.9 gal/hour
22.3 l/hour
Max pull8485 lbs
3848 kg
