New Holland T6.175 Auto Command
|
|
| Production | |
| Manufacturer | New Holland (a part of CNH) |
| Row-Crop tractor | |
| Original price was $153,260 in 2015 | |
| Variants | |
| T6.175 Value | economy |
| T6.175 Plus | mid-spec |
| T6.175 Elite | premium |
| T6.175 CVT | AutoCommand |
| New Holland T6.175 Auto Command Engine | |
| FPT 4.5L 4-cyl diesel | |
| Exhaust fluid (DEF) | 9.7 gal 36.7 L |
 Engine details ... | |
| New Holland T6.175 Auto Command Transmission | |
| continuously variable transmission (CVT) | |
 Transmission details ... |
| New Holland T6.175 Auto Command Power | |
| Engine | 145 hp 108.1 kW |
| PTO (claimed) | 120 hp 89.5 kW |
| Drawbar (tested) | 88.4 hp 65.9 kW |
| PTO (tested) | 135.6 hp 101.1 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Wet disc brakes | |
| Horizon cab standard with air-conditioning and Comfort Ride cab suspension. ISOBUS II ((Optional)); AutoGuidance ((Optional)) | |
| Photos | |
| No photos of the New Holland T6.175 Auto Command are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load sensing |
| Rear valves | 3 to 4 |
| Mid valves | 0 to 3 |
| Pump flow | 33 gpm 124.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| III/II | |
| Rear lift (at ends) | 11649 lbs 5283 kg |
| Front Hitch | optional |
| Drawbar | Cat. 3 |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Front PTO | optional |
| Dimensions & Tires | |
| Wheelbase | 104 inches 264 cm |
| Suspension Wheelbase | 105.7 inches 268 cm |
| SuperSteer Wheelbase | 109.8 inches 278 cm |
| Weight | 10605 to 15245 pounds |
| Front tire | 380/85R28 |
| Rear tire | 460/85R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 150 |
| 200 OptOptional | |
| Battery CCA | 1300 |
| Battery volts | 12 |
| References | |
 | |
| New T6: More Features. More Farming. published in 2015, by New Holland | |
| T6 Series published in 2024, by New Holland |
