McCormick Intl CX90
| 2000 - 2004 |
CX Series | Utility tractor |
|
Production |
Manufacturer: | McCormick Intl (a part of Argo)
|
Type: | Utility tractor
|
Factory: | Doncaster, England
|
McCormick Intl CX90 Power |
Engine: | 90 hp 67.1 kW
|
Mechanical |
Chassis: | 4x2 2WD
|
| 4x4 MFWD 4WD
|
Steering: | power
|
Brakes: | wet disc
|
Cab: | Cab standard.
|
Transmission: | 16-speed two-speed power shift
|
Transmission details ... |
Photos |
No photos of the McCormick Intl CX90 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics |
Type: | open center
|
SCV flow: | 15.85 gpm 60.0 lpm
|
Tractor hitch |
Rear Type: | II
|
Rear lift: | 8543 lbs 3875 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Clutch: | hydraulic wet disc
|
Rear RPM: | 540/1000 (1.375)
|
Engine RPM: | 540@2000 1000@2000
|
Electrical |
Ground: | negative
|
Battery volts: | 12
|
