John Deere 5100MH
|
|
| Production | |
| Manufacturer | John Deere |
| High-Clearance tractor | |
| John Deere 5100MH Engine | |
| John Deere 4.5L 4-cyl diesel | |
 Engine details ... |
| John Deere 5100MH Transmissions | |
| 12-speed | |
| 16-speed | |
 Transmission details ... |
| John Deere 5100MH Power | |
| Engine (gross) | 100 hp 74.6 kW |
| PTO (claimed) | 85 hp 63.4 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Power steering | |
| Hydraulic wet disc brakes | |
| Two-post ROPS. Cab optional. | |
| Photos | |
| No photos of the John Deere 5100MH are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 37 gal 140.0 L |
| Hydraulic system | 14 gal 53.0 L |
| Hydraulics | |
| Type | open center |
| Capacity | 14 gal 53.0 L |
| Pressure | 2900 psi 200.0 bar |
| SCV flow | 18.4 gpm 69.6 lpm |
| Total flow | 24.7 gpm 93.5 lpm |
| Steering flow | 6.3 gpm 23.8 lpm |
| Steering press. | 1950 psi 134.5 bar |
| Tractor hitch | |
| Rear Type | II |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/540E |
| Engine RPM | 540@2100 |
| 540E@1645 | |
| Dimensions & Tires | |
| Wheelbase | 90.6 inches 230 cm |
| Weight | 8300 to 9300 pounds |
| Front tire | 230/95R40 |
| Rear tire | 230/95R40 |
 Full dimensions and tires ... | |
| 5100MH Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 90 |
| 120 *Available as a field-installed option. | |
| Battery CCA | 950 |
| Battery volts | 12 |
| References | |
 | |
| Specialty Tractors published in 2012, by John Deere |
