Tractors > J.I. Case > 1070

J.I. Case 1070



J.I. Case 1070 tractor photo
1970 - 1978
Model year
70 Series
Row-Crop tractor
Series map:
970
1070
95.6hp*
112.2hp*
*Estimated engine power for comparison only.
Production
ManufacturerJ.I. Case
Row-Crop tractor
Built in Racine, Wisconsin, USA
Total built7,561
Original price was $22,600 in 1978
J.I. Case 1070 Engine
J.I. Case 7.4L 6-cyl diesel
Fuel tank50 gal
189.2 L
Engine details ...
J.I. Case 1070 Transmissions
8-speed unsynchronized gear
12-speed partial powershift
Transmission details ...
J.I. Case 1070 Power
Drawbar (claimed)85 hp
63.4 kW
PTO (claimed)101 hp
75.3 kW
Drawbar (tested)90.99 hp
67.9 kW
PTO (tested)108.10 hp
80.6 kW
Performance test details ...
Mechanical
Two-wheel drive
Steeringhydrostatic power
Differential hydraulic dry disc brakes
Cab optional
Photos
No photos of the J.I. Case 1070 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Valves2
Pump flow16 gpm
60.6 lpm
Tractor hitch
Rear TypeII
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Dimensions & Tires
Weight10,310 lbs
4676 kg
Front tire10.00-16
Rear tire18.4-34
Full dimensions and tires ...
1070 Serial Numbers
Location:Plate on instrument panel
19708650001
19718674001
19728691801
19738712001
19748736601
19758770001
19768797501
19778809950
19788830001

FAQ: How to read a serial number table.
References
1070 references literature
1975 Spring Buyers Guide published by J.I. Case
Time-saving experts published in 1975, by J.I. Case
"Specializing" for Specialists published in 1978, by J.I. Case
