Steiger Tiger III ST-450
|
|
| Production | |
| Manufacturer | Steiger |
| Four-wheel Drive (4WD) tractor | |
| Built in Fargo, North Dakota, USA | |
| Steiger Tiger III ST-450 Engine | |
| Caterpillar 18.0L 8-cyl diesel | |
 Engine details ... |
| Steiger Tiger III ST-450 Transmission | |
| 6-speed full power shift with torque converter | |
 Transmission details ... |
| Steiger Tiger III ST-450 Power | |
| Engine | 450 hp 335.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | planetary |
| Articulated power steering | |
| Hydraulic disc brakes | |
| Safari Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Steiger Tiger III ST-450 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 385 gal 1457.2 L |
| Hydraulic system | 48 gal 181.7 L |
| Hydraulics | |
| Type | open center |
| Capacity | 48 gal 181.7 L |
| Pressure | 2250 psi 155.1 bar |
| Valves | 5 |
| Pump flow | 35 gpm 132.5 lpm |
| SCV flow | 25 gpm 94.6 lpm |
| Dimensions & Tires | |
| Wheelbase | 150 inches 381 cm |
| Weight | 45360 lbs 20575 kg |
| Front tire | 30.5-32 |
| Rear tire | 30.5-32 |
 Full dimensions and tires ... | |
| Tiger III ST-450 Serial Numbers | |
| 1980 | 129-00001 |
| 1981 | 129-00010 |
| 1982 | 129-01501 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 90 |
| Batteries | 4 |
| Battery CCA | 625 |
| Battery volts | 12 |
| References | |
 | |
| Tiger III ST 450 published in 1979, by Steiger |
