Massey Ferguson 7726


Massey Ferguson 7726 tractor photo
2015 - 2018
7700 Series
Row-Crop tractor
7626
Series:77247726
7726S
Production
Manufacturer:Massey Ferguson (a part of AGCO)
Type:Row-Crop tractor
Factory:Beauvais, France
Original price:$187,403 (2015 Dyna-6 Classic )
Original price:$232,833 (2015 Dyna-VT Premium )
Massey Ferguson 7726 Power
Engine (gross):240 hp
179.0 kW
PTO (claimed):200 hp
149.1 kW
Drawbar (tested):169.6 hp
126.5 kW
PTO (tested):235.9 hp
175.9 kW
power test details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:full-locking electro-hydraulic
Steering:power
Brakes:wet disc
Cab:Cab standard with air-conditioning. AGCOMMAND ready
Transmissions:24-speed six-speed power shift
 continuously-variable transmission (CVT)
Transmission details ...
Photos
No photos of the Massey Ferguson 7726 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:114 gal
431.5 L
Exhaust fluid (DEF):14 gal
53.0 L
Hydraulic system:26.4 gal
99.9 L
Hydraulics
Type:closed center load sensing
Capacity:26.4 gal
99.9 L
Pressure:2900 psi
200.0 bar
Valves:3 to 5
Pump flow:29 gpm
109.8 lpm
 39 gpm
147.6 lpm *Optional with Dyna-6 transmission.
 50 gpm
189.3 lpm *Optional with Dyna-VT transmission
SCV flow:24.3 gpm
92.0 lpm
Tractor hitch
Rear Type:III
Control:electronic lower-link draft sensing
Rear lift (at ends):13500 lbs
6123 kg *With Dyna-6 transmission
 15500 lbs
7030 kg *With Dyna-VT transmission
Front Hitch:IIIN
Front lift (at ends):7954 lbs
3607 kg
Drawbar:Cat. 3
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
 540/540E/1000
 540E/1000E/1000
 540/540E/1000/1000E
Dimensions & Tires
Weight:16535 lbs
7500 kg
Front tire:420/90R30
Rear tire:480/80R46
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:175
 240*Dual 120A alternators on Deluxe and Premium models.
Batteries:2
Battery CCA:600
Battery volts:12
