Kubota L1-22
|
|
| Production | |
| Manufacturer | Kubota |
| Compact Utility tractor | |
| Variants | |
| L1-22DT | 4WD |
| Kubota L1-22 Engine | |
| Kubota 1.5L 3-cyl diesel | |
| Fuel tank | 7.7 gal 29.1 L |
 Engine details ... | |
| Kubota L1-22 Transmission | |
| 16-speed shuttle | |
 Transmission details ... |
| Kubota L1-22 Power | |
| Engine | 21.7 hp 16.2 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Wet disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Kubota L1-22 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | I |
| Power Take-off (PTO) | |
| Rear PTO Type | 540/770/940/1250 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 61 inches 154 cm |
| Weight | 2105 to 2227 pounds |
| Front tire | 4.00-15 |
| 2WD Rear tire | 9.5-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Instruction Manual L1 (31351-1921-6) |
