New Holland Boomer 47
| | 2014 - 2016 |
| Boomer Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | New Holland
|
| Type: | Compact Utility tractor
|
| New Holland Boomer 47 Power |
| Engine (gross): | 45.6 hp
34.0 kW
|
| Gear PTO (claimed): | 37.3 hp
27.8 kW
|
| Hydro PTO (claimed): | 35 hp
26.1 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | mechanical rear
|
| Steering: | hydrostatic power
|
| Brakes: | wet discs
|
| Cab: | Two-post foldable ROPS. Cab optional with air-conditioning.
|
| Transmissions: | hydrostatic
|
| | 16-speed partially synchronized with mechanical shuttle
|
 Transmission details ... |
| Hydraulics |
| Type: | open center
|
| Valves: | 1 or 2
|
| Pump flow: | 8.2 gpm
31.0 lpm
|
| Gear Steering flow: | 4.2 gpm
15.9 lpm
|
| Hydro Steering flow: | 5.3 gpm
20.1 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| Rear lift (at ends): | 2756 lbs
1250 kg
|
| Rear lift (at 24"/610mm): | 2116 lbs
959 kg
|
| Rear Arms: | adjustable draft link ends
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic
|
| Rear RPM: | 540 (1.375)
|
| Mid PTO: | independent
|
| Mid RPM: | 2000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 85
|
| Battery volts: | 12
|
