TYM T254


TYM T254 tractor photo
2014 -
Compact Utility tractor
Production
Manufacturer:TYM
Type:Compact Utility tractor
TYM T254 Power
Engine (gross):24.2 hp
18.0 kW
TYM T254 Engine
Yanmar 1.3L 3-cyl
Fuel tank:5.3 gal
20.1 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Brakes:wet disc
Cab:Two-post foldable ROPS.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the TYM T254 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center dual gear pump
Valves:1*Optional
Total flow:7.1 gpm
26.9 lpm
Tractor hitch
Rear Type:I
Control:position control
Rear lift (at ends):1323 lbs
600 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540 (1.375)
Engine RPM:540@2893
Mid PTO:independent*Optional
Mid RPM:2000
Engine RPM:2000@2875
Dimensions & Tires
Wheelbase:57.5 inches
146 cm
Weight:1610 lbs
730 kg
Front tire:6.0-12
Rear tire:9.5-16
Full dimensions and tires ...
TYM T254 attachments
60" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:40
Battery volts:12
