John Deere 5075M



John Deere 5075M tractor photo
2008 - 2025
Model year
5M Series
Utility tractor
Series map:
5075M
5085M
75.0hp
85.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Augusta, Georgia, USA
Original price was $59,242 in 2021
John Deere 5075M Engine
John Deere 2.9L 3-cyl diesel
ROPS Fuel tank30 gal
113.6 L
Cab Fuel tank36 gal
136.3 L
Engine details ...
John Deere 5075M Transmissions
12-speed partially synchronized
16-speed power shuttle
32-speed two-speed power shift
Transmission details ...
John Deere 5075M Power
Engine (gross)75 hp
55.9 kW
PTO (claimed)57.7 hp
43.0 kW
PTO (tested)72.80 hp
54.3 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Isolated open operator station with foldable two-post ROPS. Optional premium open station features extended fenders and integral work lights. Standard and premium cabs available with air-conditioning.
Photos
No photos of the John Deere 5075M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2900 psi
200.0 bar
Pump flow18.4 gpm
69.6 lpm
SCV flow14.6 gpm
55.3 lpm
Steering flow6.3 gpm
23.8 lpm
Steering press.1900 psi
131.0 bar
Tractor hitch
Rear TypeII/I
Controllower-link draft sensing
Rear lift (at 24"/610mm)4793 lbs
2174 kg
 5935 lbsOptOptional
2692 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E
 540/540E/1000 OptOptional
Engine RPM540@2100
 540E@1645
 1000@2100
Dimensions & Tires
Wheelbase90.6 inches
230 cm
Weight7100 to 8500 pounds
Front tire12.4R24
2WD Rear tire18.4R30
Full dimensions and tires ...
John Deere 5075M attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps90
 120 *The 120A alternator is a field-installed option.
Battery CCA950
Battery volts12
Battery AH180
References
5075M references literature
5M Series published in 2015, by John Deere
5M Series published in 2016, by John Deere
5M Series published in 2018, by John Deere*
5M Tractors published in 2022, by John Deere
Operator's Manual 5094M, 5090M, 5100M, 5100MH, 5100ML, 5115M and 5115ML (FT4) Tractors (OMSU54598) published in 2017
*Publication contains known errors.
