Eagle Manufacturing H 20-40


No photo available
1922 - 1930
Standard-tread tractor
Production
Manufacturer:Eagle Manufacturing
Type:Standard-tread tractor
Factory:Appleton, Wisconsin, USA
Eagle Manufacturing H 20-40 Power
Drawbar (claimed):20 hp
14.9 kW
Belt (claimed):40 hp
29.8 kW
Eagle Manufacturing H 20-40 Engine
Eagle Manufacturing 16.5L 2-cyl kerosene
Engine details ...
Mechanical
Chassis:4x2 2WD
Final drives:spur gear
Steering:manual
Cab:Open operator station.
Transmission:2-speed gear
Transmission details ...
Photos
No photos of the Eagle Manufacturing H 20-40 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Weight:7840 lbs
3556 kg
Rear tire:52x18
Full dimensions and tires ...
Belt Pulley
Diameter:24 inches
60 cm
Width:10 inches
25 cm
RPM:450
Speed:2800 ft/min
853.44 meters/min
