Kubota B40


Kubota B40 tractor photo
1988 - 1992
Sub-Compact Utility tractor
Production
ManufacturerKubota
Sub-Compact Utility tractor
Kubota B40 Engine
Kubota 0.9L 3-cyl diesel
Fuel tank4.5 gal
17.0 L
Engine details ...
Kubota B40 Power
Engine14 hp
10.4 kW
Mechanical
Four-wheel drive
Open operator station.
Tractor hitch
Rear TypeJIS0
Power Take-off (PTO)
Rear PTO Type540 (1.375)
Engine RPM447@2600
 814@2600
 1228@2600
Dimensions & Tires
Wheelbase49 inches
124 cm
Weight1213 lbs
550 kg
Front tire5.00-12
Rear tire8-16
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
B40 references literature
B-40 (67148-6291-3)
