Tractors > McCormick Intl > X7.460

McCormick Intl X7.460



McCormick Intl X7.460 tractor photo
2013 - 2021
X7.4 Series
Row-Crop tractor
Series map:
X7.450
X7.460
111.9kw
119.3kw
Production
ManufacturerMcCormick Intl (a part of Argo)
Row-Crop tractor
McCormick Intl X7.460 Engine
BetaPower 4.5L 4-cyl diesel
Fuel tank74 gal
280.1 L
Exhaust fluid (DEF)10 gal (early)
37.9 L
 13.7 gal (late)
51.9 L
Engine details ...
McCormick Intl X7.460 Transmissions
24-speed four-speed power shift
30-speed six-speed power shift
continuously-variable transmission
Transmission details ...
McCormick Intl X7.460 Power
Engine160 hp
119.3 kW
Engine (max)166 hp
123.8 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Wet disc brakes
Trailer brakeshydraulic (optional)
 pneumatic (optional)
Cab standard with air-conditioning. Optional electro-hydraulic cab suspension.
Photos
No photos of the McCormick Intl X7.460 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed-center load-sensing OptOptional
Valves3 to 6
Pump flow23.3 gpm (open center)
88.2 lpm
 32.5 gpm (closed center)
123.0 lpm
Steering flow11.6 gpm
43.9 lpm
Tractor hitch
Rear TypeIII/IIIN
Controllower link draft sensing
Rear lift13889 lbs
6300 kg
 20503 lbsOptOptional
9300 kg
Front HitchII OptOptional
Front lift7716 lbs
3499 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet discs
Rear PTO Type540/1000 (1.375)
Front PTOindependent (optional)
Dimensions & Tires
Wheelbase102.4 inches
260 cm
Weight12680 lbs
5751 kg
Front tire540/65R28
Rear tire650/65R38
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
X7.460 references literature
X7 published in 2018, by McCormick
