McCormick Intl X7.440



McCormick Intl X7.440 tractor photo
2013 - 2021
X7.4 Series
Row-Crop tractor
Series map:
X7.440
X7.450
97.7kw
111.9kw
Production
ManufacturerMcCormick Intl (a part of Argo)
Row-Crop tractor
McCormick Intl X7.440 Engine
BetaPower 4.5L 4-cyl diesel
Fuel tank74 gal
280.1 L
Exhaust fluid (DEF)10 gal (early)
37.9 L
 13.7 gal (late)
51.9 L
Engine details ...
McCormick Intl X7.440 Transmissions
24-speed four-speed power shift
30-speed six-speed power shift
continuously-variable transmission
Transmission details ...
McCormick Intl X7.440 Power
Engine131 hp
97.7 kW
Engine (max)143 hp
106.6 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Wet disc brakes
Trailer brakeshydraulic (optional)
 pneumatic (optional)
Cab standard with air-conditioning. Optional electro-hydraulic cab suspension.
Photos
McCormick X7.440 with Ross-More FL105 front-end loader.
McCormick Intl X7.440 photos...
Hydraulics
Typeopen center
 closed-center load-sensing OptOptional
Valves3 to 6
Pump flow23.3 gpm (open center)
88.2 lpm
 32.5 gpm (closed center)
123.0 lpm
Steering flow11.6 gpm
43.9 lpm
Tractor hitch
Rear TypeIII/IIIN
Controllower link draft sensing
Rear lift13889 lbs
6300 kg
 20503 lbsOptOptional
9300 kg
Front HitchII OptOptional
Front lift7716 lbs
3499 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet discs
Rear PTO Type540/1000 (1.375)
Front PTOindependent (optional)
Dimensions & Tires
Wheelbase102.4 inches
260 cm
Weight12680 lbs
5751 kg
Front tire540/65R28
Rear tire650/65R38
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
X7.440 references literature
X7 published in 2015, by McCormick
X7 published in 2018, by McCormick
