LS XR4040
|
|
| Production | |
| Manufacturer | LS |
| Compact Utility tractor | |
| LS XR4040 Engine | |
| Shibarua 2.2L 4-cyl diesel | |
| Fuel tank | 10.5 gal (ROPS) 39.7 L |
| 12.4 gal (Cab) 46.9 L | |
 Engine details ... | |
| LS XR4040 Transmission | |
| 16-speed synchro shuttle | |
 Transmission details ... |
| LS XR4040 Power | |
| Engine (gross) | 40 hp 29.8 kW |
| PTO (claimed) | 32.4 hp 24.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Wet disc brakes | |
| Two-post foldable ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the LS XR4040 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 8.2 gpm 31.0 lpm |
| Total flow | 12.4 gpm 46.9 lpm |
| Steering flow | 4.2 gpm 15.9 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position and draft control |
| Rear lift | 2756 lbs 1250 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent (optional) |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 69.4 inches 176 cm |
| Weight | 3870 to 4330 pounds |
| Front tire | 9.5-16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| LS XR4040 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 85 |
| Battery volts | 12 |
| References | |
 | |
| XR4000 Series published in 2016, by LS |
