LS XR3037H
|
|
| Production | |
| Manufacturer | LS |
| Compact Utility tractor | |
| LS XR3037H Engine | |
| Shibarua 1.5L 3-cyl diesel | |
| Fuel tank | 10.5 gal (ROPS) 39.7 L |
| 12.4 gal (Cab) 46.9 L | |
 Engine details ... | |
| LS XR3037H Transmission | |
| hydrostatic | |
 Transmission details ... |
| LS XR3037H Power | |
| Engine (gross) | 36.2 hp 27.0 kW |
| PTO (claimed) | 29.2 hp 21.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Wet disc brakes | |
| Two-post foldable ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the LS XR3037H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 8.2 gpm 31.0 lpm |
| Total flow | 13.4 gpm 50.7 lpm |
| Steering flow | 5.2 gpm 19.7 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position and draft control |
| Rear lift | 1808 lbs 820 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent (optional) |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 66 inches 167 cm |
| Weight | 3220 to 3590 pounds |
| Front tire | 7-14 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| LS XR3037H attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 85 |
| Battery volts | 12 |
| References | |
 | |
| XR3000 Series published in 2015, by LS |
