Tractors > CaseIH > Magnum 250

CaseIH Magnum 250 Tests



CaseIH Magnum 250 tractor photo
2014 - 2025
Model year
Magnum Series
Row-Crop tractor
Series map:
Magnum 250
Magnum 280
250.0hp
280.0hp
OCED Tractor Test 2122A
Magnum 250 fuel use from test 985A
OCED Tractor Test 2122A
Diesel 18-speed 4WD
September 1 - 17, 2015
Link: OCED Tractor Test 2122A file
PTO performance
Max power261.49 hp
195.0 kW
Fuel use13.5 gal/hour
51.1 l/hour
Power at rated engine speed215.51 hp
160.7 kW
Fuel use11.9 gal/hour
45.0 l/hour
Power at rated PTO speed261.49 hp
195.0 kW
Fuel use13.5 gal/hour
51.1 l/hour
Drawbar performance
Max power183.85 hp
137.1 kW
Fuel use11.7 gal/hour
44.3 l/hour
Gear 8 used for power test.
Max pull20729 lbs
9402 kg
Gear 4 used for pull test.
