TYM T290
| | 2001 - 2009 |
| Compact Utility tractor |
|
Series map:
T290
T300
31.0hp
31.0hp
| Production |
| Manufacturer | TYM
|
| Compact Utility tractor |
| Built in South Korea |
| TYM T290 Power |
| Engine | 31 hp
23.1 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post ROPS. |
| Photos |
| No photos of the TYM T290 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Tractor hitch |
| Rear Type | I
|
| Control | position and draft control
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2541
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 50
|
| Battery volts | 12
|
| References |
 |
| Operator's Manual for T290/T300/T330 (1350-912-002-0) published in 2005 |
| Page information |
 |
| Copyright 2026 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on July 22, 2026 |
