TYM T603
| | 2006 - ???? |
| Compact Utility tractor |
|
| Production |
| Manufacturer: | TYM
|
| Type: | Compact Utility tractor
|
| TYM T603 Power |
| Engine (gross): | 58 hp
43.3 kW
|
| PTO (claimed): | 46.6 hp
34.7 kW
|
| Mechanical |
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post ROPS. Cab optional.
|
| Transmissions: | 24-speed synchronized shuttle
|
| | 24-speed power shuttle
|
 Transmission details ... |
| Capacity |
| Fuel: | 18.48 gal
69.9 L
|
| Hydraulic system: | 11 gal
41.6 L
|
| Front axle: | 17.4 qts
16.5 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 11 gal
41.6 L
|
| Valves: | 2
|
| Pump flow: | 10.5 gpm
39.7 lpm
|
| Total flow: | 15.1 gpm
57.2 lpm
|
| Steering flow: | 4.7 gpm
17.8 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and draft control
|
| Rear lift (at ends): | 4270 lbs
1936 kg
|
| Rear lift (at 24"/610mm): | 3153 lbs
1430 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic
|
| Rear RPM: | 540/1000 (1.375)
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 65
|
| Battery volts: | 12
|
| Page information |
| Last update: | September 19, 2017
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
