Tractors > Deutz-Fahr > DX 130

Deutz-Fahr DX 130 Tests



Deutz-Fahr DX 130 tractor photo
1981 - 1983
DX Series
Row-Crop tractor
Series map:
DX 120
DX 130
DX 140
122.2hp*
133.3hp*
145.6hp*
*Estimated engine power for comparison only.
Nebraska Tractor Test 1404
DX 130 fuel use from test 1404
Nebraska Tractor Test 1404
Diesel 24-speed 2WD
September 12 - 22, 1981
Link: Nebraska Tractor Test 1404 file
PTO performance
Power at rated engine speed121.27 hp
90.4 kW
Fuel use7.3 gal/hour
27.6 l/hour
Power at rated PTO speed121.36 hp
90.5 kW
Fuel use6.9 gal/hour
26.1 l/hour
Drawbar performance
Max power102.63 hp
76.5 kW
Fuel use7.3 gal/hour
27.6 l/hour
Gear 3MH used for power test.
Max pull14406 lbs
6534 kg
Gear 1ML used for pull test.
