CaseIH Puma 240


CaseIH Puma 240 tractor photo
2014 - 2023
Model year
Puma Series
Row-Crop tractor
Puma 230
Series:Puma 220Puma 240
Production
Manufacturer:CaseIH
Type:Row-Crop tractor
Factory:Basildon, England
Original price:$216,959 (2015 )
CaseIH Puma 240 Power
Engine:240 hp
179.0 kW
PTO (claimed):205 hp
152.9 kW
Drawbar (tested):173.2 hp
129.2 kW
PTO (tested):228.6 hp
170.5 kW
power test details ...
CaseIH Puma 240 Engine
FPT 6.7L 6-cyl diesel
Fuel tank:103 gal
389.9 L
Exhaust fluid (DEF):12.7 gal
48.1 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Trailer brakes:hydraulic*Optional
 pneumatic*Optional
Cab:Cab standard with air-conditioning.
Transmissions:18-speed full power shift
 continuously variable transmission (CVT)
Transmission details ...
Photos
No photos of the CaseIH Puma 240 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center pressure flow compensating
Valves:3 to 5
Pump flow:30 gpm
113.6 lpm
 39.6 gpm
149.9 lpm *Optional
Total flow:47 gpm
177.9 lpm
 56.6 gpm
214.2 lpm *Optional
Steering flow:17 gpm
64.3 lpm
Tractor hitch
Rear Type:II/IIIN
Rear lift:12787 lbs
5800 kg
 15000 lbs
6804 kg *Optional
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:1000/1000E (1.75)
Dimensions & Tires
Wheelbase:113.6 inches
288 cm
Weight:16800 lbs
7620 kg
Front tire:420/85R30
Rear tire:520/85R42
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:150
Battery volts:12
Page information
