Kioti NX5510
|
|
| Production | |
| Manufacturer | Kioti (a part of Daedong) |
| Compact Utility tractor | |
| Kioti NX5510 Engine | |
| Daedong 1.8L 3-cyl diesel | |
| Fuel tank | 14.8 gal 56.0 L |
 Engine details ... | |
| Kioti NX5510 Transmissions | |
| 24-speed synchro shuttle | |
| hydrostatic | |
 Transmission details ... |
| Kioti NX5510 Power | |
| Engine (gross) | 55 hp 41.0 kW |
| Gear PTO (claimed) | 46 hp 34.3 kW |
| Hydro PTO (claimed) | 43.1 hp 32.1 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | rear standard |
| Steering | hydrostatic power |
| Wet discs brakes | |
| Two-post foldable ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the Kioti NX5510 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center gear pump |
| Valves | 0 to 2 |
| Gear Pump flow | 16.5 gpm 62.5 lpm |
| Hydro Pump flow | 17.9 gpm 67.8 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and draft control |
| Rear lift (at 24"/610mm) | 3177 lbs 1441 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | optional |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 75.6 inches 192 cm |
| Weight | 4211 to 4579 pounds |
| Front tire | 9.5-16 |
| Rear tire | 13.6-28 |
 Full dimensions and tires ... | |
| Kioti NX5510 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| NX Series published in 2018, by Kitoi |
