Massey Ferguson 7614



Massey Ferguson 7614 tractor photo
2013 - 2014
7600 Series
Row-Crop tractor
Series map:
7614
7615
130.0hp
140.0hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Row-Crop tractor
Built in Beauvais, France
Massey Ferguson 7614 Engine
Sisu 6.6L 6-cyl diesel
Engine details ...
Massey Ferguson 7614 Transmission
16-speed four-speed power shift
Transmission details ...
Massey Ferguson 7614 Power
Engine (net)130 hp
96.9 kW
PTO (claimed)110 hp
82.0 kW
Drawbar (tested)100.6 hp
75.0 kW
PTO (tested)135.6 hp
101.1 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic standard
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic (optional)
 pneumatic (optional)
Cab standard. Optional hydraulic OptiRide cab suspension. AGCOCOMMAND (optional); Auto-Guide 3000 (optional)
Photos
Massey Ferguson 7614
Massey Ferguson 7614 photos...
Capacity
Fuel82 gal
310.4 L
Exhaust fluid (DEF)8 gal
30.3 L
Hydraulic system26.4 gal
99.9 L
Hydraulics
Typeclosed-center load sensing (CCLS)
 open center OptOptional
Capacity26.4 gal
99.9 L
Pressure2900 psi
200.0 bar
Valves3 (mechanical)
 4 (2 mech, 2 elec)
 4 (electric)
SCV flow24.3 gpm
92.0 lpm
Total flow29 gpm
109.8 lpm
Tractor hitch
Rear TypeIII
Controlelectronic lower link draft sensing
Rear lift (at ends)9800 lbs
4445 kg
Front Hitchoptional
DrawbarCat. II with drop pin
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000 (1.375)
 540/540E/1000 (1.375)
 540/540E/1000/1000E (1.375)
Engine RPM540@1980
 540E@1533
 1000@2030
 1000E@1572
Dimensions & Tires
Wheelbase113.1 inches
287 cm
Weight15060 lbs
6831 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps120
 175 (option)
 240 (dual 120 option)
Batteries2
Battery volts12
References
7614 references literature
7600 Series published in 2013, by Massey Ferguson
