Massey Ferguson 1736


Massey Ferguson 1736 tractor photo
2013 - 2018
1700 Series
Compact Utility tractor
1635
Series:17361742
1735M
Production
Manufacturer:Massey Ferguson
Type:Compact Utility tractor
Original price:$23,428 (2018 shuttle ROPS )
Massey Ferguson 1736 Power
Engine:36.2 hp
27.0 kW
PTO (claimed):27.5 hp
20.5 kW
Massey Ferguson 1736 Engine
Mitsubishi 1.7L 3-cyl diesel
Fuel tank:10.6 gal
40.1 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:bull gear
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional with air-conditioning.
Transmissions:12-speed power shuttle
 hydrostatic
Transmission details ...
Hydraulics
Type:open center gear pump
Valves:1 to 3
SCV flow:11.6 gpm
43.9 lpm
Tractor hitch
Rear Type:I
Control:position control
 draft control*Optional
Rear lift (at 24"/610mm):2535 lbs
1149 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540 (1.375)
Mid PTO:optional
Mid RPM:2000
Dimensions & Tires
Wheelbase:69.7 inches
177 cm
Weight:3362 to 3803 pounds
Front tire:8-16
Rear tire:12.4-24
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
