Kubota L5060


Kubota L5060 tractor photo
2013 -
L60 Series
Compact Utility tractor
L5040
Series:L4760L5060L5460
Production
Manufacturer:Kubota
Type:Compact Utility tractor
Kubota L5060 Power
Engine (gross):52 hp
38.8 kW
Engine (net):50 hp
37.3 kW
PTO (claimed):44 hp
32.8 kW
Kubota L5060 Engine
Kubota 2.4L 4-cyl diesel
Fuel tank:13.5 gal
51.1 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post foldable ROPS
Transmission:12-speed
Transmission details ...
Photos
No photos of the Kubota L5060 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:9.8 gpm
37.1 lpm
Total flow:14.7 gpm
55.6 lpm
Steering flow:4.9 gpm
18.5 lpm
Tractor hitch
Rear Type:I
Control:position control, draft control optional
Rear lift (at 24"/610mm):2976 lbs
1349 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
Mid PTO:optional
Mid RPM:2000
Dimensions & Tires
Wheelbase:75.4 inches
191 cm
Weight:3979 lbs
1804 kg
Front tire:9.5-16
Rear tire:14.9-26
Full dimensions and tires ...
Kubota L5060 attachments
snowblower
blade
front-end loader
backhoe
Attachment details ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:45
Battery volts:12
