Jeep CJ-3A
|
|
| Production | |
| Manufacturer | Jeep |
| Truck-type tractor | |
| Built in Toledo, Ohio, USA | |
| Jeep CJ-3A Engine | |
| Willys 2.2L 4-cyl gasoline | |
 Engine details ... |
| Jeep CJ-3A Transmission | |
| 6-speed sliding gear | |
 Transmission details ... |
| Jeep CJ-3A Power | |
| Engine | 60 hp 44.7 kW |
| Plows | 2 (12-inch) |
| Drawbar (tested) | 25.94 hp 19.3 kW |
| Belt (tested) | 28.43 hp 21.2 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Steering | manual |
| Hydraulic drum brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Jeep CJ-3A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | I |
| Power Take-off (PTO) | |
| Rear PTO | optional |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 80 inches 203 cm |
| Weight | 2037 lbs 923 kg |
| Front tire | 6x16 |
| Rear tire | 6x16 |
 Full dimensions and tires ... | |
| Belt Pulley | |
| Diameter | 8 inches 20 cm |
| Width | 8 inches 20 cm |
| RPM | 1550 |
| Speed | 3246 ft/min 989.38 meters/min |
| Electrical | |
| Ground | negative |
| Battery volts | 6 |
| References | |
 | |
| Jeep Farm Power |
