TYM T350
| | 2009 - ???? |
| 300 Series | | Compact Utility tractor |
|
Series map:
T300
T350
T353
30.0hp
35.0hp
35.0hp
| Production |
| Manufacturer | TYM
|
| Compact Utility tractor |
| TYM T350 Power |
| Engine (gross) | 35 hp
26.1 kW
|
| PTO (claimed) | 29 hp
21.6 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | hydrostatic power
|
| Wet disc brakes |
| Two-post ROPS. |
| Photos |
| No photos of the TYM T350 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 7.3 gal
27.6 L
|
| Hydraulic system | 8.7 gal
32.9 L
|
| Front axle | 2.2 qts
2.1 L
|
| Hydraulics |
| Type | dual gear pump
|
| Capacity | 8.7 gal
32.9 L
|
| Pump flow | 6.3 gpm
23.8 lpm
|
| Total flow | 10.6 gpm
40.1 lpm
|
| Steering flow | 4.3 gpm
16.3 lpm
|
| Tractor hitch |
| Rear Type | 1
|
| Control | position control
|
| Rear lift (at ends) | 2646 lbs
1200 kg
|
| Rear lift (at 24"/610mm) | 1764 lbs
800 kg
|
| Power Take-off (PTO) |
| Rear PTO | transmission
|
| Rear PTO Type | 540 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 50
|
| Charging volts | 12
|
| Battery volts | 12
|
