Kubota L4300
| | 2001 - 2005 |
| Standard L Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | Kubota
|
| Type: | Compact Utility tractor
|
| The Kubota L4300 was an "economy" version of the L4310. It was only available with an unsynchronized 8-speed gear transmission and no cab was offerd. |
| Variants |
| L4300F: | 2WD
|
| L4300DT: | 4WD
|
| Kubota L4300 Power |
| Engine (gross): | 45.3 hp
33.8 kW
|
| PTO (claimed): | 37.5 hp
28.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Final drives: | helical gear
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post ROPS.
|
| Transmission: | 8-speed sliding gear
|
 Transmission details ... |
| Photos |
| No photos of the Kubota L4300 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Valves: | 1 to 3
|
| Pump flow: | 6.4 gpm
24.2 lpm
|
| Total flow: | 10.4 gpm
39.4 lpm
|
| Steering flow: | 3.9 gpm
14.8 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| Rear lift (at ends): | 2870 lbs
1301 kg
|
| Rear lift (at 24"/610mm): | 2310 lbs
1047 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Electrical |
| Ground: | negative
|
| Battery CCA: | 550
|
| Battery volts: | 12
|
| Battery AH: | 55
|
| Page information |
| Last update: | June 22, 2017
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
