New Holland T4.75
| | 2012 - 2014 |
| PowerStar T4 Series | | Utility tractor |
|
Series map:
T4.65
T4.75
48.5kw
55.2kw
| Production |
| Manufacturer | New Holland
|
| Utility tractor |
| New Holland T4.75 Power |
| Engine (gross) | 74 hp
55.2 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | limited slip 4WD front axle
|
| Steering | hydrostatic power
|
| Trailer brakes | hydraulic optional
|
| Two-post foldable ROPS. Optional PowerStar cab with optional air-conditioning. EZ-Guide 250 and 500 capable. |
| Hydraulics |
| Type | fixed displacement
|
| Rear valves | 3
|
| Mid valves | 2
|
| Pump flow | 12.55 gpm
47.5 lpm
|
| Steering flow | 7.3 gpm
27.6 lpm
|
| | 9.5 gpm (power shuttle)
36.0 lpm
|
| Tractor hitch |
| Rear Type | 2/1
|
| Control | mechanical draft control
|
| Rear lift (at ends) | 4,883 lbs
2214 kg
|
| Rear lift (at 24"/610mm) | 3,664 lbs
1661 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| | 540E
|
| | ground
|
| Engine RPM | 540@1958
|
| | 540E@1592
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 120
|
| Charging volts | 12
|
| Battery volts | 12
|
| Battery AH | 100
|
