John Deere 6620 Premium
| | 2001 - 2006 |
|
| 6020 Series | | Utility tractor |
|
| Production |
| Manufacturer: | John Deere
|
| Type: | Utility tractor
|
| John Deere 6620 Premium Power |
| Engine (net): | 125 hp
93.2 kW
|
| PTO (claimed): | 110 hp
82.0 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Cab standard.
|
| Transmission: | 24-speed partial power shift
|
 Transmission details ... |
| Photos |
| No photos of the John Deere 6620 Premium are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | closed center load sensing
|
| Pressure: | 2900 psi
200.0 bar
|
| Pump flow: | 25.4 gpm
96.1 lpm
|
| Tractor hitch |
| Rear Type: | II/IIIN
|
| Rear lift: | 16,360 lbs
7420 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| 6620 Premium Serial Numbers |
| Location: | Right side of main tractor frame.
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 90
|
| | 115
|
| Battery volts: | 12
|
