Bolens G274


Bolens G274 tractor photo
1983 - 1989
Compact Utility tractor
Iseki built
Production
Distributor:Bolens
Manufacturer:Iseki
Type:Compact Utility tractor
Bolens G274 Power
Engine:27 hp
20.1 kW
Bolens G274 Engine
Iseki 1.3L 3-cyl diesel
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:rear standard
Steering:power
Brakes:wet disc
Cab:Two-post ROPS.
Transmission:18-speed synchromesh
Transmission details ...
Photos
No photos of the Bolens G274 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:7.25 gal
27.4 L
Steering:2.1 qts
2.0 L
Hydraulics
Type:open center
Pressure:2000 psi
137.9 bar
Pump flow:5.5 gpm
20.8 lpm
Steering cap.:2.1 qts
2.0 L
Tractor hitch
Rear Type:1
Control:position control
Rear lift:2,500 lbs
1134 kg
Power Take-off (PTO)
Rear PTO:independent
Dimensions & Tires
Wheelbase:65 inches
165 cm
Weight:2,440 lbs
1106 kg
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging volts:35
Battery CCA:305
Battery volts:12
