Tractors > Simplicity > 9528

Simplicity 9528 Engine



Simplicity 9528 tractor photo
1978 - 1983
9500 Series
Compact Utility tractor
Hinomoto built
Series map:
9523
9528
23.0hp
28.0hp
Engine Detail
Toyosha S148
diesel
2-cylinder
liquid-cooled
Displacement90.1 ci
1.5 L
Bore/Stroke3.82x3.94 inches
97 x 100 mm
Power28 hp
20.9 kW
Fuel systemKiki PES-2K injection pump
Air cleanerdry element
Compression23:1
Rated RPM2500
Idle RPM750-2750
Firing order1-2
Starterelectric
Starter volts12
Coolant capacity5.3 qts
5.0 L
Engine Oil
9528 diesel engine oil chart
Oil capacity5 qts
4.7 L
Oil change100 h
