McCormick Intl X10.75M
|
|
| Production | |
| Distributor | McCormick Intl |
| Manufacturer | Daedong |
| Compact Utility tractor | |
| Built in South Korea | |
| McCormick Intl X10.75M Engine | |
| Perkins 4.4L 4-cyl diesel | |
| Fuel tank | 33 gal 124.9 L |
 Engine details ... | |
| McCormick Intl X10.75M Transmission | |
| 12-speed syncronized shuttle | |
 Transmission details ... |
| McCormick Intl X10.75M Power | |
| Engine (gross) | 74.4 hp 55.5 kW |
| PTO (claimed) | 58.4 hp 43.5 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | rear standard |
| Steering | hydrostatic power |
| Wet disc brakes | |
| Cab standard with air-condioning. Optional rear wiper and CD player. | |
| Photos | |
| No photos of the McCormick Intl X10.75M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 1 to 3 |
| Total flow | 22.1 gpm 83.6 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at 24"/610mm) | 5,290 lbs 2399 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Wheelbase | 90.7 inches 230 cm |
| Weight | 7,749 lbs 3514 kg |
| Front tire | 11.2x24 |
| Rear tire | 16.9x30 |
 Full dimensions and tires ... | |
| McCormick Intl X10.75M attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| X10.75M/X10.90M Cab published in 2011, by McCormick |
