Tractors > John Deere > 3100

John Deere 3100



John Deere 3100 tractor photo
1995 - 1998
Utility tractor
Renault built
Series map:
3100
3200
41.0kw
48.5kw
Production
DistributorJohn Deere
ManufacturerRenault
Utility tractor
Built in Le Mans, France
John Deere 3100 Engine
John Deere 2.9L 3-cyl diesel
Fuel tank30.4 gal
115.1 L
Engine details ...
John Deere 3100 Transmissions
10-speed synchronized
20-speed synchronized
20-speed two-speed power shift
Transmission details ...
John Deere 3100 Power
Engine (net)55 hp
41.0 kW
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Cab standard with heater.
Photos
No photos of the John Deere 3100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2611 psi
180.0 bar
Pump flow13.7 gpm
51.9 lpm
Steering flow7 gpm
26.5 lpm
Tractor hitch
Rear TypeII
Controllower-link draft sensing
Rear lift6317 lbs
2865 kg
 8430 lbsOptOptional
3823 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchmechanical
Rear PTO Type540
 540/540E OptOptional
 540/1000 OptOptional
Dimensions & Tires
Weight6548 lbs
2970 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps65
Battery volts12
Battery AH105
References
3100 references literature
New John Deere 3000 Series Tractors published in 1994
