CaseIH Steiger 550 Tests
|
|
| Steiger 535 ↑ | |||
| Series: | Steiger 500 ← | Steiger 550 | → Steiger 600 |
| Steiger 580 ↓ |
| OCED Tractor Test 2047 | |||
| |||
| OCED Tractor Test 2047 | |
| Diesel 16-speed 4WD November 8 - 16, 2012 Link: OCED Tractor Test 2047 file | |
| PTO performance | |
| Max power: | 536.32 hp 399.9 kW |
| Fuel use: | 28.0 gal/hour 106.0 l/hour |
| Power at rated engine speed: | 475.47 hp 354.6 kW |
| Fuel use: | 26.4 gal/hour 99.9 l/hour |
| Power at rated PTO speed: | 518.57 hp 386.7 kW |
| Fuel use: | 27.7 gal/hour 104.8 l/hour |
| Drawbar performance | |
| Max power: | 462.64 hp 345.0 kW |
| Fuel use: | 27.6 gal/hour 104.5 l/hour |
| Gear 5 used for power test. | |
| Max pull: | 51953 lbs 23565 kg |
| Gear 1 used for pull test. | |
