Massey Ferguson 5455
| | 2005 - 2013 |
|
| 5400 Series | | Utility tractor |
|
Series map:
5450
5455
5460
83.3hp*
105.0hp
115.0hp
| Production |
| Manufacturer | Massey Ferguson
|
| Utility tractor |
| Built in Beauvais, France |
| Original price | $40,114 (2009 ROPS 2WD )
|
| $56,539 (2009 Cab 4WD )
|
| Massey Ferguson 5455 Power |
| Engine (gross) | 105 hp
78.3 kW
|
| PTO (claimed) | 85 hp
63.4 kW
|
| Drawbar (tested) | 67.7 hp
50.5 kW
|
| PTO (tested) | 109.3 hp
81.5 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic *Optionlal
|
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Hydraulics |
| Type | open center
|
| | closed center load-sensing *Optional with cab.
|
| Valves | 2 to 4
|
| Pump flow | 15 gpm (open center)
56.8 lpm
|
| | 26 gpm (open optional)
98.4 lpm
|
| | 29 gpm (closed center)
109.8 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | electronic draft control
|
| Rear lift (at 24"/610mm) | 7817 lbs
3545 kg
|
| | 9189 lbsOptOptional
4168 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 80
|
| Battery CCA | 775
|
| Battery volts | 12
|
| References |
 |
| 5400 Series published in 2010, by Massey Ferguson |
| MF 5400 published in 2012, by Massey Ferguson |
