CaseIH D29


CaseIH D29 tractor photo
2001 - 2003
DX Series
Compact Utility tractor
Series map:
DX25
D29
DX29
25.0hp
29.0hp
29.0hp
Production
ManufacturerCaseIH
Compact Utility tractor
Variants
D29gear
DX29hydrostatic
TC29similar New Holland model
CaseIH D29 Engine
Shibaura 1.3L 3-cyl diesel
Fuel tank7.3 gal
27.6 L
Engine details ...
CaseIH D29 Power
Engine (gross)29 hp
21.6 kW
PTO (claimed)25.1 hp
18.7 kW
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Two-post fixed ROPS. Folding ROPS optional.
Photos
No photos of the CaseIH D29 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow6.6 gpm
25.0 lpm
Total flow10.1 gpm
38.2 lpm
Steering flow3.5 gpm
13.2 lpm
Tractor hitch
Rear TypeI
Rear lift (at 24"/610mm)1635 lbs
741 kg
Power Take-off (PTO)
Rear PTOtransmission
Rear PTO Type540 (1.375)
Mid PTOtransmission OptOptional
Mid PTO Type2000
Dimensions & Tires
Wheelbase63 inches
160 cm
Weight2334 to 2474 pounds
Front tire5.50x16
Rear tire11.2x24
Full dimensions and tires ...
CaseIH D29 attachments
60" mid-mount mower deck
72" mid-mount mower deck
snowblower
blade
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery CCA420
Battery volts12
References
D29 references literature
DX Series Compact Tractors published in 2003, by CaseIH
