Massey Ferguson 595


Massey Ferguson 595 tractor photo
1974 - 1982
Row-Crop tractor
Production
ManufacturerMassey Ferguson
Row-Crop tractor
Built in Beauvais, France
Massey Ferguson 595 Engine
Perkins 5.2L 4-cyl diesel
Fuel tank33.8 gal
127.9 L
Engine details ...
Massey Ferguson 595 Power
Engine86.8 hp
64.7 kW
Mechanical
Two- or four-wheel drive
Final drivesoutboard planetary
Steeringhydrostatic power
Wet disc brakes
Cab standard.
Hydraulics
Typeopen center
Pressure2400 psi
165.5 bar
Pump flow6.7 gpm
25.4 lpm
Tractor hitch
Rear Type2
Controlposition and draft control with top-link sensing
Rear lift5,400 lbs
2449 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear PTO Type540 (1.375)
 1000 (1.375)
Engine RPM540@1750
 1000@2000
Dimensions & Tires
Wheelbase104.3 inches (2WD)
264 cm
 102.4 inches (4WD)
260 cm
Weight9040 to 9900 pounds
Front tire11.00-16
Rear tire16.9-38 (2WD)
Full dimensions and tires ...
References
595 references literature
New Tractor Line 500-Series published by Massey Ferguson
