John Deere 5100GV
| | 2009 - 2013 |
| 5G Series | | Orchard/Vineyard tractor | | Agritalia built |
|
| Production |
| Distributor: | John Deere
|
| Manufacturer: | Agritalia
|
| Type: | Orchard/Vineyard tractor
|
| Factory: | Rovigo, Italy
|
| John Deere 5100GV Power |
| Engine: | 100 hp
74.6 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | ROPS (2-post)
|
| | Cab optional.
|
| Transmissions: | 12-speed
|
| | 24-speed
|
 Transmission details ... |
| Photos |
| No photos of the John Deere 5100GV are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure: | 2700 psi
186.2 bar
|
| Pump flow: | 11.9 gpm
45.0 lpm
|
| | 15.6 gpm
59.0 lpm (optional)
|
| Total flow: | 18.9 gpm
71.5 lpm
|
| | 22.3 gpm
84.4 lpm (optional)
|
| | 27.6 gpm
104.5 lpm (optional)
|
| Steering flow: | 6.5 gpm
24.6 lpm
|
| Steering press.: | 1900 psi
131.0 bar
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift: | 5,845 lbs
2651 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540/540E/ground
|
| | 540/1000/ground
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 45
|
| | 95 (cab)
|
| Battery volts: | 12
|
| Battery AH: | 100
|
