Tractors > John Deere > 6300L

John Deere 6300L



John Deere 6300L tractor photo
1992 - 1997
Orchard/Vineyard tractor
Series map:
6200L
6300L
6400L
83.0hp
93.0hp
99.0hp
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
Built in Mannheim, Baden-Württemberg, Germany
Variants
6300utility tractor
6300Llow-profile
John Deere 6300L Engine
John Deere 3.9L 4-cyl diesel
Engine details ...
John Deere 6300L Transmissions
12-speed fully synchronized
21-speed
16-speed partial power shift
28-speed partial power shift
Transmission details ...
John Deere 6300L Power
Engine93 hp
69.4 kW
PTO (claimed)75 hp
55.9 kW
Mechanical
Two- or four-wheel drive
Power steering
Differential hydraulic wet disc brakes
ROPS. Cab optional.
Photos
No photos of the John Deere 6300L are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel30 gal
113.6 L
Front axle6.8 qts
6.4 L
Front hubs3.6 qts
3.4 L
Hydraulics
Typeclosed center pressure flow compensated
Pressure2900 psi
200.0 bar
Valves2
Total flow18 gpm
68.1 lpm
 25.4 gpm (optional)
96.1 lpm
Tractor hitch
Rear TypeII
Rear lift4,900 lbs
2222 kg
Power Take-off (PTO)
Rear PTO Type540
 540/1000 (optional)
Dimensions & Tires
Wheelbase94.5 inches
240 cm
Weight7497 to 8004 pounds
Front tire27/9.5-15
Rear tire16.9-24
Full dimensions and tires ...
John Deere 6300L attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery CCA780
Battery volts12
Battery AH110
 154 OptOptional
References
6300L references literature
66- to 85-HP 6000 Series Tractors published in 1996, by John Deere
Operator's Manual 6200, 6200L, 6300, 6300L, 6400, 6400L and 6500L Tractors (OMAL77469) published in 1994
6000 Series Tractors and Advantage Series Tractors Product Information Handbook published in 1997, by John Deere
5000 Series NARROW and 6000 Series LOW-PROFILE Tractors published in 1994, by John Deere
