Claas Arion 530


Claas Arion 530 tractor photo
2007 - 2025
Model year
Arion 500 Series
Row-Crop tractor
Series map:
Arion 520
Arion 530
Arion 540
89.5kw
96.9kw
100.7kw
Production
ManufacturerClaas
Row-Crop tractor
Claas Arion 530 Engine
John Deere 4.5L 4-cyl diesel
Fuel tank66 gal
249.8 L
Engine details ...
Claas Arion 530 Transmission
24-speed partial power shift with power shuttle
Transmission details ...
Claas Arion 530 Power
Engine130 hp
96.9 kW
Mechanical
Four-wheel drive
Power steering
Trailer brakespneumatic OptOptional
Cab standard with air-conditioning.
Photos
No photos of the Claas Arion 530 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 load sensing OptOptional
Pressure2901 psi
200.0 bar
Valves2 to 6
Total flow15.9 gpm
60.2 lpm
 29.1 gpmOptOptional
110.1 lpm
Power Take-off (PTO)
Rear PTO Type540/1000
 540/540E/1000/1000E (optional)
Dimensions & Tires
Wheelbase100.8 inches
256 cm
Weight12060 lbs
5470 kg
Front tire14.9R28
Rear tire18.4R38
Full dimensions and tires ...
References
Arion 530 references literature
Arion published in 2007, by New Rules - The Arion By Claas
Arion published in 2010, by Claas
